Function of MMA&MIG,single pulse/double pulse,much compact design for 300mm coil which can be well protected internally .
Digital welding process control for precision in the welding process,exact reproducibility and outstanding properties.
Synergic operation.The optimum welding parameters can be achieved by simply selecting the material &size and stored expert parameters on the control panel .
With arc ending & spot welding ,deep molten puddle,less spatter.
| Model |
MIG300DP |
|
| Parameter |
MIG |
MMA |
| Input power voltage (V) |
AC380V±15% 3PH |
|
| Input voltage frequency (HZ) |
50/60 |
|
| Rated input power capacity (KVA) |
11 |
12.1 |
| Output current range (A) |
10-300 |
10-300 |
| No-load voltage (V) | 63 | |
| ARC force adjustment range (10A/1) |
|
0-3 |
| Spot welding time(s) |
0-20 |
|
| Spot welding interval |
0.1-3 |
|
| Duty cycle (%) |
60 |
|
| No-load consumption (W) |
60 |
|
| Spool size(mm) | 300 | |
| Wire feeding speed | 18m/min | |
| Weight (KG) | 33.4 | |
| Dimension (mm) |
550*280*580 |
|
Aerospace industry;
Automobile and component supply industry;
Maintenance and repair
Shipbuilding/offshore
